Who is ready for some "Open Heart" surgery on their aging machines?

A new modification, dubbed "Open Heart," has been developed for the Sega Genesis/Mega Drive console, offering a range of enhancements using a Raspberry Pi Pico or compatible board. This multi-mod aims to breathe new life into the classic 16-bit system by adding features that expand its functionality and user experience.

Credit: Thomas Freitas / X

The "Open Heart" mod boasts an array of features designed to improve the console's performance and versatility:

  • Switchless Region Changing: Automatically detects and switches between PAL and NTSC video standards, eliminating the need for manual switching.
  • Dual Frequency Oscillator: Ensures correct game speed in both PAL and NTSC modes.
  • In-Game Reset Function: Allows players to reset the game without physically pressing the console's reset button.
  • In-Game Switchable Overclocking: Provides the ability to increase the CPU speed, potentially improving performance in some games.
  • TMSS Bypass: Bypasses the Trade Mark Security System, allowing for greater compatibility with game cartridges.

Installation of the "Open Heart" mod involves removing the original oscillator and mounting the Raspberry Pi Pico in its place. The mod's creator provides generic installation instructions, acknowledging similarities to other existing mods, which may serve as helpful references. The instructions detail the connections required for each feature, including power, clock signals, region selection, reset, and cartridge enable.

Credit: Github

To set up the Raspberry Pi Pico, users need to download the "openheart.uf2" firmware image and flash it to the board. This is done by connecting the Pico to a computer while holding the BOOTSEL button and then dragging the UF2 file onto the device.

Credit: Github

Once installed, the "Open Heart" mod can be used with simple button combinations:

  • Reset Game: Hold A+B+C+Start for 1 second.
  • Toggle Overclock: Hold A+Start for 1 second.
  • Change Region: Press the Reset button 3 times within 3 seconds.

The creator of the "Open Heart" mod acknowledges that testing has not been possible on all versions of the Sega Genesis/Mega Drive and encourages users to proceed with caution. They also note that while the generated clock frequencies are close to the original specifications, slight variations may exist. The overclocking feature, while potentially beneficial, may also cause graphical glitches in some games due to exceeding the CPU's rated speed.

Future development plans include adding LED indicators for mode and region selection, further enhancing the user experience. The "Open Heart" mod presents an exciting opportunity for console owners to enhance their Sega Genesis/Mega Drive consoles with new features and capabilities. To follow the project, check out the Github page, and/or follow Thomas Freitas on X.
